Car Starter Systems

iDataStart - All-In-One 1-Way Remote Starter

• The iDataStart RS-1010G-HCX is a Universal, 1-Way remote star system for vehicles 1988-up
• No Key required for immobilizer bypass on most models
• The CA2HC control module is the heart and soul of every CARKIT system.
• The CA2HC control module is a single, all-purpose, web-programmable module that interacts seamlessly with your vehicle, eliminating the need for any additional “add-on” modules.
• This “all-in-one” digital remote start module includes a vehicle integration library supporting over 10,000 vehicles.
• Built with advanced built-in microcontrollers to support the high-speed CAN-BUS networks (CAN-FD) found in many 2023 and newer vehicles.
• The CA2HC Controller has an integrated LoRa/BLE antenna that removes the need to install and wire a separate windshield antenna.

Specifications:

CA2HC:

• 3 x CAN-FD interfaces
• 1 x SWC interface
• 1 x SAE-J1850 interface
• 4 x Vehicle data interfaces
• 4 x iDataLink interface ports
• 3 x 32bit ARM processors
• 5 x High power relays
• 2 x Low power relays
• 1 x USB-C
• 12 x Programmable outputs
• 10 x Digital inputs
• 4 x Diagnostic LEDs
• 1 x Siren output
• RFID interface

Remotes:

• 2 x 5 button, 1-Way remotes
• Over 1/4 mile of range
• Black and Grey colors
• 2 x CR2016 batteries
• Start / Stop buttons
• Lock / Unlock buttons
• Trunk release button
• Function button
• Encrypted identification
• Secure transmission
• Multi-color LED indicator
• Sound notification
• Low battery indication
• Metal keychain ring

Harness: ADS-AHR-HCX

• 8 Pin high-power connector
• 20 Pin vehicle connector
• 12 Pin output connector
• 10 Pin input connector
• 6 Pin relay connector
• 6 Pin CAN connector

Kit Includes:

• 1 x R210 (Black)
• 1 x R210G (Grey)
• Two 5 button, 1-Way remotes
• Over 1/4 mile of range
• 2x CR2016 batteries
• 1 year warranty

• Please click here for vehicle compatibility and additional information.
